Pressure Gauge

Overview

Pressure gauge for fire protection system; designed and manufactured to FM2311; FM approved; Working Temperature: 0-80C / 32-176F; Wiring Inlet Size: 1/4" NPT; Materials: base HPb59-1, watchcase 1008/PC, spring pipe Qsn0.8-2, pointer Al; Nominal Pressure (varies): 0-300PSI, 0-600PSI; Part numbers: 2 (see Part Numbers sheet)
